HS-B series automatic“inline flexo printer folder gluer”auto bundle machine

HS-B series automatic“inline flexo printer folder gluer”auto bundle machine

    • HS-B series automatic“inline flexo printer folder gluer”auto bundle machine
    • HS-B series automatic“inline flexo printer folder gluer”auto bundle machine
    • HS-B series automatic“inline flexo printer folder gluer”auto bundle machine
    • HS-B series automatic“inline flexo printer folder gluer”auto bundle machine
    • HS-B series automatic“inline flexo printer folder gluer”auto bundle machine
    • HS-B series automatic“inline flexo printer folder gluer”auto bundle machine
    • HS-B series automatic“inline flexo printer folder gluer”auto bundle machine
    • HS-B series automatic“inline flexo printer folder gluer”auto bundle machine

    Product Details:

    Contact Now
    Detailed Product Description

    Machine video link:
    https://youtu.be/rjPcroeazlY
    www.youtube.com/watch?v=w_mcx1egr_s
    www.youtube.com/watch?v=m50s7I0-qus
    www.youtube.com/watch?v=soIw7200Dxo
    www.youtube.com/watch?v=jftI-8Z8Ffw
    www.youtube.com/watch?v=pHeGpzBGbVU

    HS-B series automatic corrugated carton box “inline flexo folder gluer “ include feeding unit, print unit, slotting, die cutting unit, folder gluer unit and auto bundle unit. Fully computerized slotting unit. Carton box height length width computerized setting. Vacuum transfer folder gluer unit, one time finishing the carton box printing, cutting and gluing. Easy to change order. Suitable for the big and middle carton box factory.


    Machine UnitMain specification
    Feeder unit

    1. Lead edge feeder, feeding air pressure is adjustable
    2. dust suction brush with fan absorb
    3. motorized side squaring
    3. motorized adjust the side and back cardboard hold plate

    Print unit

    1. touch screen control printer roller phase movement
    2. hanging plate device. Easy to put printing palte
    3. have the 0 line, save printing memory
    4. ink automatic circulation. Lack ink alarm device

    Slotter unit

    1. touch screen control box height
    2. touch screen control box length and width.
    3. save box size memory

    Die cutter unit

    1. Die-cutting roll pneumatic self-locking device
    2. speed difference compensation mechanism
    3. rubber grinding knife
    4. Taiwan or Italy die cutter rubber

    Folder gluer unitBottom folder gluer
    Vacuum transfer cardboard
    big gluing wheel, reticulation gluing, motorized control glue wheel position.
    Box size touch screen computerized adjust
    Auto bundle unitPP Belt bundle
    Automatic square the carton
    one line bundle or two line bundle



    MAIN PARAMETER
    Model 920924122412281628
    Max. design speed(pcs/min)250250200200160

    Working speed (pcs/min)

    (according cardboard size and printing )

    		0-2000-1800-1800-1600-140
    Max feeding size (mm)900 × 2000900 × 24001200x24001200x28001600x2800
    Max printing size(mm)850 × 1950850 × 23501150x23501150x27501550x2750
    Min. feeding size (mm)300 × 765300 × 765360x785360x785450x850
    Min fold size 240x120240x120250x120250x120270x120
    Standard printing plate thickness7.2 mm7.2 mm7.2mm7.2mm7.2mm
    Max. Die cutting size(mm)850 × 1950 mm850 ×2250 mm1150x23501150x27501550x2750

    (Size can be customized according to customer requirements)
